Key Points on Chapter 20: Electric Potential and Capacitance

• is the potential energy per unit charge.
• Electric potential is the same as electric potential energy.
• The unit of electric potential is .
• Sometimes the electric potential is referred to as .
• Charge $\times$ voltage equals .
• An (eV) is a unit of energy.
• The voltage drop between 2 points is path .
• All points on an surface have the same electric potential or voltage.
• The electric field is to equipotential surfaces.
• Electric potential is analogous to .
• Electric potential is a (not a vector).
• The potential of produced by several charges is the of their individual potentials.
• The field is minus the of the potential.
• Electric potential energy is in fixed charges.
• An isolated conductor is an .
• A has 2 isolated conductors.
• A capacitor stores .
• Capacitance depends only on the of the conductors.
• A capacitor stores .
• is stored in an electric field.
• A increases the capacitance.
• Add capacitances to find the equivalent capacitance $C_{eq}$ of capacitors in .
• Add capacitances to find the equivalent inverse capacitance $1/C_{eq}$ of capacitors in .

Lectures on Chapter 20: Electric Potential and Capacitance

Gravitational force and electrostatic force are similar:

$$F_{\rm grav}=G \frac{m_{1}m_{2}} {r^{2}} \hspace*{1.5in}F_{e}=\frac{1}{4 \pi \varepsilon_{0}}\frac{q_{1}q_{2}}{r^{2}}$$

Recall that we can define a gravitational potential energy. If the work done to lift an object from $\underline{a}$ to $\underline{b}$ is

$$W_{ab} = \int_{a}^{b} \vec{F}_{\rm grav} \cdot d \vec{s}$$

then the potential energy gained by the object is

$$\Delta U = U_{b} - U_{a} = - W_{ab} = - \int_{a}^{b} \vec{F}_{\rm grav} \cdot d \vec{s}$$

For example, a mass $m$ a distance $h$ above the ground has potential energy

=1.75 true in

$$\Delta U = + m g h$$ (1)

The energy is measured with respect to the ground $(U = 0 \mbox{at} h =0)$, but we could put the zero of energy anywhere. It would just add a constant to $U_{a}$ and $U_{b}$ but wouldn't change the potential energy difference $U(h) - U$(ground).

Since gravity is a conservative force, $U_{b} - U_{a}$ is independent of the path taken between $a$ and $b$. All that matters is the endpoints.

In analogy with this, we can define the change in the electric potential energy.

$$\Delta U = -W_{ab} = - \int_{a}^{b} \vec{F}_{e} \cdot d \vec{s}$$

If we have a charge $q$ that finds itself in an electric field $\vec{E}$, then it feels a force

$$\vec{F}_{e} = q \vec{E}$$

$\vec{E}$ is due to other charges, e.g., another point charge. The electric potential energy associated with dragging the charge from $a$ to its present position $b$ is the negative of the work done in getting it there.

$$\Delta U = - W_{ab} = - \int_{a}^{b} \vec{F}_{e} \cdot d \vec{s} = - \int_{a}^{b} q \vec{E} \cdot d \vec{s}$$

$d \vec{s}$ goes along the path we took from $a$ to $b$. Like gravity, $\vec{F}_{e}$ is a conservative force so that $\Delta U$ depends only on the endpoints $a$ and $b$, not on the path between them.

Notice that the sign of $\Delta U$ will change in $q \rightarrow -q$. So if the field comes from positive charges and $q>0$, we do work in dragging $q$ toward the charges and $\Delta U$ increases. If $q<0$, then $q$ is attracted to the positive charges and drags us toward them; $\Delta U$ decreases and is negative. (It's like the difference between uphill and downhill.)

Let's take $q>0$. Notice that the bigger $q$ is, the more work we do in dragging it around, and the bigger the potential energy is. Remember how it was convenient to divide $\vec{F}_{e}$ by $q$ to get $\vec{E}$.

$$\vec{E} = \frac{\vec{F}_{e}}{q} \nonumber$$

$\vec{E}$ is independent of $q$ that feels it but doesn't produce it. For example, consider the force on $q$ produced by a point charge $q_1$.

$$F_{q\leftarrow q_1} = \frac{1}{4 \pi \varepsilon_{0}} \frac{q_{1}q}{r^{2}}$$ (2)

The force depends on $q$ and $q_{1}$, but the electric field $\vec{E}$ produced by $q_{1}$

$$\vec{E} = \frac{\vec{F}}{q} = \frac{1}{4 \pi \varepsilon_{0}} \frac{q_{1}}{r^{2}}\hat{r}$$ (3)

depends only on $q_{1}$. It does not depend on $q$.

Similarly, it is convenient to divide $U$ by $q$ to get something independent of $q$.

$$\Delta V = \frac{\Delta U}{q} \;\;\;\; \mbox{potential energy per charge}$$

$V$ is called the electric potential.

$$\Delta V = \frac{\Delta U}{q} = - \int_{a}^{b} \frac{1}{q} \vec{F}_{e} \cdot d \vec{s} = - \int_{a}^{b} \vec{E} \cdot d \vec{s}$$

This depends on only on the charges that produce $\vec{E}$. Just as $\vec{E}$ was the force felt by a unit charge $(q=1)$, $\Delta V$ is the potential energy of a unit charge, i.e., $\Delta V$ is the potential energy per unit charge.

is the potential energy per unit charge.

Electric potential is the same as electric potential energy.

Units

The unit of electric potential is .

Sometimes the electric potential is referred to as .

$[\Delta U]$ = joules (after all, it's an energy)
$[\Delta V] = \frac{{\rm joules}}{{\rm coulomb}} = {\rm volts}$
So electric potential $\Delta V$ and electric potential energy are different. Sometimes the electric potential is referred to as voltage.

Charge $\times$ voltage equals .

An (eV) is a unit of energy.

Notice that if there is potential difference $\Delta V = 1 {\rm volt}$, the potential energy gained by moving a proton with charge $+e$ through this difference (``uphill" or against the field) is $\Delta U = e \Delta V = 1 e V =$ 1 electron volt.

=2.0 true in

An $eV$ is a unit of energy:

$$1 {\rm eV} = e\; (1V) = (1.60 \times 10^{-19} C)(1 \frac{J}{C}) = 1.60 \times 10^{-19} J$$

In general, moving a charge $q$ through a voltage drop $\Delta V$ changes its potential energy by $\Delta U$.

$$\Delta U = q \Delta V$$

So a big voltage can give a small $\Delta U$ if $q$ is small. For example, rubbing your hair with a balloon can charge the balloon to several thousand volts but the amount of charge is small $(\sim 10^{-6}$ C) so $\Delta U$ is small $\Longrightarrow$ you won't get electrocuted.

The voltage drop between 2 points is path .

The gravitational analog is $U_{\rm grav}/m = gh$. Just as with gravity, $\Delta V = V_{b} - V_{a}$ depends only on where $a$ and $b$ are, not on the path between them. Thus it doesn't matter whether you take path 1 or path 2, $\Delta V$ is the same. (The gravitational analog of $E=\frac{F}{q}$ was $F/m = g =$ acceleration.)

=2.0 true in

You can think of $\frac{U_{\mbox{grav}}}{m}=gh$ as gravitational potential (if you multiply by $m$, you get gravitational potential energy). Think of different distances up a hill. Higher points on the hill have greater gravitational potential. Going uphill is like acquiring a higher voltage by dragging a positive charge opposite to the field. ``Danger: High Voltage" are like ``Danger: Falling rocks" signs.

Equipotential Surfaces

All points on an surface have the same electric potential or voltage.

An equipotential surface is the set of points which all have the same electric potential or voltage. These points are usually a surface.

$$\Delta V = V_{b} - V_{a}$$ (4)

If $a$ and $b$ are on the same equipotential surface, then $V_{b} = V_{a}$ and $\Delta V = 0$. Look at

$$\Delta V = V_{b} - V_{a} = - \int_{a}^{b} \vec{E} \cdot d \vec{s}$$ (5)

How can $\Delta V = 0$? One way: $\vec{E} = 0$ everywhere along $d \vec{s}$ (like inside a conductor). Another way: $\int\vec{E} \cdot d\vec{s} = 0. \int \vec{E} \cdot d \vec{s}$ is a line integral along the path parameterized by $\vec{s}$. $\int \vec{E} \cdot d \vec{s}$ adds up all the components of $\vec{E}$ along $d \vec{s}$. $\vec{E} \cdot d \vec{s} = \vert \vec{E} \vert\vert d \vec{s}\vert \cos \theta$. If $\vec{E} \perp d \vec{s}$, then $\theta = \frac{\pi}{2} = 90^{\circ}$, $\vec{E} \cdot d \vec{s}=0$. So $\Delta V = 0$ on surfaces $\perp \vec{E}$.

=2.0 true in

The electric field is to equipotential surfaces.

Examples:

=5.0 true in

All points on the surface have the same potential but different surfaces have different potentials. Gravitational analogy: Every point at the same altitude $h$ has the same gravitational potential $gh$. $\vec{F}_{{\rm grav}} \perp$ to equipotential surfaces. $\vec{F}_{{\rm grav}}$ points along the fall line on a slope.

=3.5 true in

Potential in a Uniform Field

Electric potential is analogous to .

Electric potential is the analog of height on a hill. Notice that the height difference between points $a$ and $b$ is the same as the height difference between points $a$ and $c$.

=2.0 true in

Similarly the potential difference between points $a$ and $b$ is the same as the potential difference between points $b$ and $c$ in the figure of equipotential planes in a uniform electric field. Dragging a mass uphill corresponds to dragging a positive charge from $a$ to $c$ or from $a$ to $b$.

=3.0 true in

The potential difference between points $a$ and $c$ is given by

$$\begin{eqnarray*} \Delta V&=&V_c-V_a=-\int_{a}^{c}\vec{E}\cdot d\vec{s}=-\vec{E}... ...=-Er\cos\phi\\ &=& -Er\cos(\pi-\theta) =Er\cos\theta=Ed=V_b-V_a \end{eqnarray*}$$

We can take $\vec{E}$ out of the integral because the field is constant. It's a uniform field that is the same everywhere. So we see that in a uniform field the potential is $E$ times the perpendicular distance between equipotential surfaces.

Dimensional analysis: Notice that $[V]=[Ed]$ implies that voltage or potential has the same units as electric field times length or (Newtons/Coulomb) $\times$ meters = Joules/Coulomb=Volts. Similarly, $[E]=[V/d]$ which means that electric field has units of Volts/meter = V/m. Earlier we learned that $[E]=[Force/Charge]=$ Newtons/Coulomb. So 1 V/m = 1 N/C.

Potential of a Point Charge

Consider a point charge $q>0$ at the origin. Infinitely far away, a test charge $q_{0}$ feels no force $\Longrightarrow \vec{E} = 0$ at $\infty$. So let's set $U_{\infty} = 0$ and $V_{\infty} = 0$ because there is no potential energy and no potential at $r = \infty$. What is the potential $V(r)$ a distance $r$ away from $q$? If we start at $r$ and push $q_{0} > 0$ to infinity, then

$$\Delta V = V \mbox{(end)} - V \mbox{(start)} = V (\infty) - V(r) = - V(r) < 0$$

This is less than 0 because we lose potential energy; we are going downhill.

=2.5 true in

$$\Delta V = - \int_{r}^{\infty} \vec{E} \cdot d \vec{s}$$

$$= -\int_{r}^{\infty} \vec{E} \cdot d \vec{r}$$

$$\vec{E} = \frac{1}{4 \pi \varepsilon_{0}} \frac{q}{r^{2}} \hat{r} \Longrightarrow \vec{E} \parallel d \vec{r} \Longrightarrow \vec{E} \cdot d \vec{r} = Edr$$

$$\Delta V = -V(r)= - \int_{r}^{\infty} E d r^{\prime} = - \frac{1}{4 \pi \varepsilon_{0}} \int_{r}^{\infty} \frac{q}{r^{\prime 2}} d r^{\prime}$$

$$= - \frac{1}{4 \pi \varepsilon_{0}} \left[ - \frac{q}{r^{\prime}} \right]^{r^{\prime}= \infty}_{r^{\prime}=r}$$

$$= \frac{1}{4 \pi \varepsilon_{0}} \left[ 0 - \frac{q}{r} \right]$$

$$-V(r) = -\frac{1}{4 \pi \varepsilon_{0}} \frac{q}{r}$$

$$V(r) = \frac{1}{4 \pi \varepsilon_{0}} \frac{q}{r} > 0$$ (6)

If $q \rightarrow -q$, $V(r) = - \frac{1}{4 \pi \varepsilon_{0}} \frac{q}{r} <0$. So $V$ changes sign if $q$ changes sign. $V(r)$ falls off slower than $E \sim 1/r^2$. Notice that $V(r) >0$ which means that if we started at $r = \infty$ and dragged a charge $q_{0}$ to the point $r$, its potential energy would increase:

$$U(r) = q_{0} V(r) = \frac{1}{4 \pi \varepsilon_{0}} \frac{q q_{0}}{r}$$

One of the great benefits of $V$ is that it is a scalar, so we don't have to find the components of a vector. $V(r)$ is a scalar field, i.e., a number is associated with every point in space.

Electric potential is a (not a vector).

Superposition

The potential of produced by several charges is the of their individual potentials.

To find the potential of a group of charges at a point $\vec{r}$, add the potential $V_{i}$ at $\vec{r}$ due to each charge $q_{i}$:

$$V = \sum_{i = 1}^{n} V_{i} = \frac{1}{4 \pi \varepsilon_{0}} \sum_{i=1}^{n} \frac{q_{i}}{r_{i}}$$

Because $V$ is a scalar, we can add magnitudes. We don't have to worry about vector components.

Potential of an Electric Dipole

=2.5 true in

$$V = \sum_{i=1}^{2} V_{i} = V_{+} + V_{-} = \frac{1}{4 \pi \varepsilon_{0}} \left[ \frac{q}{r_{+}} + \frac{(-q)}{r_{-}} \right]$$

$$= \frac{q}{4 \pi \varepsilon_{0}} \left[ \frac{1}{r_{+}} - \frac{1}... ...frac{q}{4 \pi \varepsilon_{0}} \left[ \frac{r_{-} - r_{+}}{r_{-} r_{+}} \right]$$

For $r»d$, $r_{+} r_{-} \approx r^{2}$ and $(r_{-} - r_{+}) \approx d \cos \theta$

$$V = \frac{q}{4 \pi \varepsilon_{0}} \frac{d \cos \theta}{r^{2}} \hspace*{1.5in} p = qd$$

$$= \frac{p \cos \theta}{4 \pi \varepsilon_{0} r^{2}} \hspace*{1.5in} V(r) \;=\;\mbox{scalar field set up by dipole}$$

Azimuthal symmetry (rotational symmetry about z-axis) $\Longrightarrow$ no $\phi$ dependence. In the equatorial plane, $\theta = 90^{\circ} \Longrightarrow V=0$ because $V_{+}$ and $V_{-}$ cancel $(V_{+} = - V_{-})$.

Continuous Charge Distribution

Given $q(\vec{r^{\prime}})$, find $V(\vec{r})$.

Recipe for Finding the Potential due to a Continuous Charge Distribution

Method I

1. Divide charge distribution into pieces with charge $dq$.
2. $dq$ produces a potential $dV = \frac{1}{4 \pi \varepsilon_{0}} \frac{dq}{r}$ where $r$ is the distance from $dq$ to the point $P$.
3. $V = \int d V = \frac{1}{4 \pi \varepsilon_{0}} \int \frac{dq}{r}$. Integrate over the charge distribution. (Notice this assumes $V=0$ at $r= \infty)$

Method II

1. Use Gauss' Law to find $\vec{E}$ if there is symmetry.
2. Use $\Delta V = - \int_{a}^{b} \vec{E} \cdot d \vec{s}$

Example Using Method II: Charged Planar Sheet

Consider an infinite (insulating) sheet with uniform positive charge density $\sigma$. What is the change in potential in going from $z_{1}$ to $z_{2}$, where $z_{1}$ and $z_{2}$ are distances from the sheet?

=3.0 true in

Solution
Use $V(z_{2}) - V(z_{1}) = - \int_{z_{1}}^{z_{2}} \vec{E} \cdot d \vec{s}$

1. Find $\vec{E}$ using Gauss' Law:


   $$\varepsilon_{0} \int \vec{E} \cdot d \vec{a} = q_{{\rm enc}}$$

   $$2 \varepsilon_{0} E A = \sigma A$$

   $$E = \frac{\sigma}{2 \varepsilon_{0}}$$



   Notice that $\vec{E}$ is uniform, i.e., it's the same everywhere.
2. We saw earlier that the potential difference between 2 points in a uniform field is $Ed$. Since $z_2$ is further from the sheet of charge than $z_1$, we expect $V(z_{2}) - V(z_{1})<0$. So $V(z_{2}) - V(z_{1})=-Ed$. We can also go through the math again:


   $$V(z_{2}) - V(z_{1}) = - \int_{z_{1}}^{z_{2}} \vec{E} \cdot d \vec{s}$$

   $$= - \int_{z_{1}}^{z_{2}} E d z = - E \int_{z_{1}}^{z_{2}} dz$$

   $$= -E (z_{2} - z_{1}) = - \frac{\sigma}{2 \varepsilon_{0}} (z_{2} - z_{1})$$

   $$V(z_{2}) - V(z_{1}) = -\frac{\sigma}{2\varepsilon_{0}}(z_{2}-z_{1})< 0$$




Calculating the field from the potential

The field is minus the of the potential.

$$\vec{E} = - \nabla V$$ (7)

We've seen how to calculate the potential $V$ if we know $\vec{E}: \Delta V = - \int_{a}^{b} \vec{E} \cdot d\vec{s}$.

How do we calculate $\vec{E}$ if we know $V$?

$$V = - \int \vec{E} \cdot d \vec{s} \Longrightarrow d V = - \vec{E} \cdot d \vec{s}$$

Suppose $d\vec{s}= dx\;\hat{i}$ ($d \vec{s}$ is in the $\hat{i}$ direction.) Then

$$dV = - \vec{E} \cdot dx\; \hat{i} = - E_{x} dx$$

$$\Longrightarrow E_{x} = - \frac{\partial V}{\partial x}$$

If $d \vec{s} = d y\; \hat{j}$, then

$$dV = -E_{y} dy \rightarrow E_{y} = - \frac{\partial V}{\partial y}$$ (8)

If $d \vec{s} = dz\; \hat{k}$, then

$$dV = - E_{z}dz \Longrightarrow E_{z} = - \frac{\partial V}{\partial z}$$ (9)

In general we can write

$$\vec{E} = E_{x} \hat{i} + E_{y} \hat{j} + E_{z} \hat{k}$$

$$= - \frac{\partial V}{\partial x} \hat{i} - \frac{\partial V}{\partial y} \hat{j} - \frac{\partial V}{\partial z} \hat{k}$$

$$= - \nabla V$$ (10)

where $\nabla V$ is called ``the gradient of $V$.'' What does this mean? Recall the equipotential surfaces, each with constant $V$. $\vec{E}$ is perpendicular to the surfaces and points from high potential to low potential, i.e., ``downhill". So if you put a + charge where $V=5$ volts, it would feel a force $\vec{F}$ in the direction of $V=0$ volts. $\vec{F} \parallel \vec{E}$.

Think of a hill. Equipotential corresponds to equi-altitude. $\vec{E}$ would point straight downhill, i.e. along the ``fall line".

Electric fields are high near the tips of lightning rods which is why they get struck by lightning first.

Example: If $V(\vec{r})=5x-3y+z^2$, what is $\vec{E}$?

$$\begin{eqnarray*} E_x &=& -\frac{\partial V}{\partial x}=-\frac{\partial (5x)}{\... ...ial z}=-2z\\ \vec{E} & =& -5\;\hat{i} +3\;\hat{j} -2z\; \hat{k} \end{eqnarray*}$$

Electric Potential Energy due to a System of Charges

Electric potential energy is in fixed charges.

The electric potential energy of a system of fixed point charges is equal to the work done to assemble the changes, bringing one at a time in from infinity.

=2.0 true in

Consider assembling 3 point charges. Bring in one charge at a time. No work to bring in $q_{1}$, but $q_{1}$ sets up a potential

$$V_{1} = \frac{1}{4 \pi \varepsilon_{0}} \frac{q_{1}}{r}$$ (11)

where $r$ is the distance from $q_1$. Now bring in $q_{2}$. The energy we store in doing this is

$$U_{12} = q_{2} V_{1} = \frac{1}{4 \pi \varepsilon_{0}} \frac{q_{1}q_{2}}{r_{12}}$$ (12)

where $r_{12}$ is the distance between $q_{2}$ and $q_{1}$. (The work we do is minus the work done by the field, so $U=W_{US} = - W_{\vec{E}\;{\rm of}\; q_{1}}$.)

Note that the general formula for the potential energy of a pair of point charges a distance $r$ apart is

$$U = \frac{1}{4 \pi \varepsilon_{0}} \frac{q_{1}q_{2}}{r}$$

$q_{2}$ also sets up a potential $V_{2} = \frac{1}{4 \pi \varepsilon_{0}}\frac{q_{2}}{r}$

When we bring in $q_{3}$, we add more potential energy.

$$U_{13} + U_{23} = \frac{1}{4 \pi \varepsilon_{0}} \frac{q_{1}q_{3}}{r_{13}} + \frac{1}{4 \pi \varepsilon_{0}} \frac{q_{2}q_{3}}{r_{23}}$$

So the total electric potential energy stored is

$$U_{\rm tot} = U_{12} + U_{13} + U_{23} = \frac{1}{4 \pi \varepsil... ..._{1}q_{3}}{r_{13}} + \frac{1}{4 \pi \varepsilon_{0}} \frac {q_{2}q_{3}}{r_{23}}$$

An Isolated Conductor

An isolated conductor is an .

Recall that $\vec{E} = 0$ inside an isolated conductor. If $\vec{E}$ were not zero, then the free conduction electrons would feel $\vec{F} = q \vec{E}$ and they would run. A charged, isolated conductor has charges on the surface because the charges get as far apart as possible. They arrange themselves such that $\vec{E} = 0$ inside. There is no charge inside because Gauss' law tells us that

$$\epsilon _0 \oint \vec{E}\cdot d\vec{a}= q_{enc} = 0 \quad\mbox{because} \quad\vec{E}= 0$$ (13)

$V$ = Constant throughout a conductor, i.e., a conductor is an equipotential. Pick 2 points $a$ and $b$ in the conductor or on its surface.

$$\begin{eqnarray*} &&V_b - V_a = - \int^b_a \vec{E}\cdot d\vec{s} = 0 \qquad\qqua... ...along surface} \end{array}\\ && \Longrightarrow \quad V_b = V_a \end{eqnarray*}$$

=2.0 true in

$\vec{E}\perp$ surface of a conductor

If $\vec{E}$ has a component along the surface, the charges would run along the surface. Here $\vec{E}$ can be either due to charges on the surface of the conductor or due to an external field $\vec{E}_{ext}$. If an uncharged conductor is placed in an external field, the conduction electrons feel the field and race to the surface, arranging themselves until they cancel the field $\vec{E}_{ext}$ inside the conductor. This ``induced charge" produces a field $\vec{E}_{ind}$ such that $\vec{E}_{ind} + \vec{E}_{ext} = 0$ inside the conductor.

=2.0 true in

Capacitors

A has 2 isolated conductors.

A capacitor stores and .

So far we've been considering a single isolated conductor. Now consider 2 isolated conductors. This is a capacitor. The conductors are called capacitor plates. Capacitors are important circuit elements. They are also used to store energy.

To understand how they work, consider a parallel plate capacitor consisting of 2 parallel conducting plates a distance $d$ apart. Each plate has area $A$. When the capacitor is charged, its plates have equal and opposite charges $+q$ and $-q$. Each plate has a constant potential, but there is a potential difference $V$ between the plates. (Conventional notation: $V = \Delta V =$ potential difference between the plates.) $V$ is proportional to $q$. (``$q$" is called ``the charge of the capacitor," even though both plates are charged.)

=2.0 true in

$$\begin{eqnarray*} q = C\Delta V \end{eqnarray*}$$

The constant of proportionality $C$ is called the capacitance of the capacitor.

A capacitor holds charge; it's sort of a charge bucket. It can store charge. The value of $C$ tells us how well the capacitor holds charge. $C$ is the ``figure of merit''. Look at $q = C\Delta V$. If $C$ is large, a small value of the voltage difference $\Delta V$ will still give a large value of the charge $q$. On the other hand, if $C$ is small, a large value of the voltage difference $\Delta V$ will still give a small value of the charge $q$. So a large value of $C$ is like a large charge bucket and a small value of $C$ is like a small charge bucket.

Units

$$\begin{eqnarray*}[C]= \frac{[q]}{[\Delta V]} = \frac{{\rm Coulomb}}{{\rm volt}} = {\rm farad} \end{eqnarray*}$$

$$\begin{eqnarray*} \mbox{1 farad} = 1F = \frac{\mbox{1 coulomb}}{\mbox{1 volt}} \end{eqnarray*}$$

1 farad is huge. Typical units: $1\mu F = 10^{-6} F$ and $1p F = 10^{-12}F.$ Notice that there is an electric field between the capacitor plates. $\vec{E}$ points from the $+q$ plate to the $-q$ plate.

=2.0 true in

The $+q$ plate is at a higher voltage than the $-q$ plate. The potential difference between the plates is

$$\begin{eqnarray*} \Delta V &=& - \int\limits^{d(+)}_{0(-)}\vec{E}\cdot d\vec{s}=... ...=& + \int\limits^{d}_{0} E ds = \int\limits^{d}_{0} Edz = Ed \end{eqnarray*}$$

Notice that $\Delta V \propto E$. How do we get $Q = C\Delta V$ from this? Recall Gauss' law:

$$\begin{eqnarray*} \epsilon_0 \oint \vec{E}\cdot d\vec{a}= q_{enc} \qquad {\rm or}\qquad E = \frac{1}{4\pi\epsilon _{0}}\int \frac{dq}{r^2} \end{eqnarray*}$$

This implies $E \propto q$. Since $\Delta V\propto E\propto q$, $\Delta V \propto q$. Thus $\Delta V = \frac{q}{C}$ or $q = C\Delta V$.

Calculating Capacitance

Capacitance depends only on the of the conductors.

$C$ depends only on the geometry of the conductors, i.e., their size, shape, and separation. $C$ is independent of $q$ and $\Delta V$. In a typical problem, you are given the geometry of the conductors and asked to find the capacitance $C$. $(C > 0$ always.)

Recipe to find the capacitance

1)

Assume $+q$ on one plate and $-q$ on the other plate (or surface charge density $\sigma = q/A$ on one plate, $\sigma = - q/A$ on another plate).

2)

Use Gauss' law to find $\vec{E}$ between the plates.

3)

Use $\Delta V = \int\limits^{(+)}_{(-)} \vec{E}\cdot d\vec{s}$ to find the potential difference between the plates. Note that we want $\Delta V > 0$.

4)

Use $q = C\Delta V \Longrightarrow C = \frac{q}{\Delta V}$ to find $C$. (The charge you put on the plates in step 1 will cancel out.)

Example: Parallel Plate Capacitor

Find the capacitance of a parallel plate capacitor with area $A$ and separation $d$. $(\sqrt{A} » d \Longrightarrow$ neglect fringing fields.)

=2.0 true in

Solution: Put $+q$ on the top plate and $-q$ on the bottom plate. Then the top plate has $\sigma_+ = q/A$ surface charge density and the bottom plate has $\sigma_- = -q/A$. The charge on each plate is attracted to the side facing the other plate. No excess charge is on the outer surfaces. Find $\vec{E}$ using Gauss' law.

=3.0 true in

$$\varepsilon_o \oint\vec{E}\cdot d\vec{a}=q_{enc}\quad \Longr... ...tarrow E = \frac{\sigma_+}{\epsilon_0} = \frac{q}{\epsilon_0A}$$ (14)

where we used $\sigma_+ = q/A$

Find $\Delta V$ using

$$\begin{eqnarray*} \Delta V &=& - \int\limits^{(+)}_{(-)} \vec{E}\cdot d\vec{s}= ... ...z = E\int\limits^{d}_{0} dz = Ed\\ &=& \frac{q}{\epsilon _0A} d \end{eqnarray*}$$

where we used $d\vec{s}=dz\;\hat{z}$ and $\vec{E}\cdot d\vec{z}=Edz\cos(180^o)$.

Find

$$C = \frac{q}{\Delta V} = \frac{q}{qd/\epsilon _0A} = \frac{\epsilon _0 A}{d}$$ (15)

Notice that this just depends on the size and separation of the plates, not on $q$ or $\Delta V$. $C$ increases with $A$ and decreases with increasing $d$. It is more convenient to express

$$\begin{eqnarray*} \epsilon _0 = 8.85 \times 10^{-12} \frac{\rm F}{\rm m} = 8.85 {\rm pF/m} \end{eqnarray*}$$

(Before we used different units: $\epsilon _0 = 8.85 \times 10^{-12}$ C$^2$/(N-m$^2$)).

If the plates are 1 mm apart $(d = 10^{-3}m)$ and $C = 1F$, how big are the plates?

$$\begin{eqnarray*} A = \frac{d}{\epsilon _0} C = \frac{(10^{-3}{\rm m})(1{\rm F})} {8.85 \times 10^{-12}{\rm F}/{\rm m}} = 1.13\cdot 10^8{\rm m}^2 \end{eqnarray*}$$

If the plates are square, then each side is

$$\begin{eqnarray*} \sqrt{A} = 1.0 \times 10^4 {\rm m} = 10\; {\rm km} \qquad\quad {\rm huge!} \end{eqnarray*}$$

Example: Cylindrical Capacitor

Consider 2 coaxial cylinders of length $L$ and radii $a$ and $b$. Find the capacitance $C$.

=2.0 true in

Solution: Assume the inner cylinder has charge $+q$ and $\sigma_+ = q/A_+ = q/2\pi aL$. The outer cylinder has $-q$ and $\sigma_- = - q/A_{-} = -q/2\pi bL$.
Find $\vec{E}$ using Gauss' law. The Gaussian surface is a cylinder of length $\ell < L, a < r < b$.

$$\begin{eqnarray*} \epsilon _0 \oint \vec{E}\cdot d\vec{a}&=& q_{enc} \Longrighta... ...l\\ \vec{E}&=& \frac{1}{\epsilon _0} \frac{\sigma_+a}{r}\hat{r} \end{eqnarray*}$$

Find $\Delta V$:

$$\begin{eqnarray*} \Delta V = - \int\limits^{(+)}_{(-)}\vec{E}\cdot d\vec{s}\quad... ...quad -\Delta V = -\int\limits^{(-)}_{(+)} \vec{E}\cdot d\vec{s} \end{eqnarray*}$$

where we switched limits so that $\vec{E}\vert\vert d\vec{r}\vert\vert d\vec{s}$.

$$\begin{eqnarray*} -\Delta V &=& - \int\limits^{(-)}_{(+)} \vec{E}\cdot d\vec{s}=... ...ight) = \frac{q}{2\pi\epsilon _0L} \ln \left( \frac{b}{a}\right) \end{eqnarray*}$$

Find $C$:

$$q = C\Delta V \quad \Longrightarrow\quad C = \frac{q}{\Delta V}$$ (16)

$$\begin{eqnarray*} C = \frac{q}{\Delta V} = \frac{q}{\frac{q}{2\pi\epsilon _0 L}\... ...ight)} = 2\pi \epsilon _0 \frac{L}{\ln\left( \frac{b}{a}\right)} \end{eqnarray*}$$

Again $C$ only depends on geometrical quantities.

Spherical Capacitor

A spherical capacitor consists of 2 concentric spherical conducting shells of radii $a$ and $b$. Find the capacitance $C.$

=2.0 true in

Solution: Assume the inner sphere has charge $+q$. Find $\vec{E}$ between the spheres. We know that outside the sphere of charge $+q$, $\vec{E}$ is the same as for a point charge:

$$\vec{E}= \frac{q}{4\pi\epsilon _0r^2}\hat{r}\hspace*{2in}$$ (17)

We could also use Gauss' law: $\epsilon _0\oint \vec{E}\cdot d\vec{a}= q_{enc}$

$$\epsilon _0 E\cdot 4\pi r^2 = q \quad \Longrightarrow \quad E = \frac{q}{4\pi\epsilon _0r^2}$$ (18)

Find the potential difference between the spheres

$$\begin{eqnarray*} \Delta V &=& - \int\limits^{(+)}_{(-)}\vec{E}\cdot d\vec{s}\qu... ...frac{q}{4\pi\epsilon _0} \left[\frac{1}{a}-\frac{1}{b}\right]\\ \end{eqnarray*}$$

$$\begin{eqnarray*} C &=& \frac{q}{\Delta V} = \frac{q}{\frac{q}{4\pi\epsilon _0}}... ...ox{Note that $C$ just depends}\\ \mbox{on geometry} \end{array}\end{eqnarray*}$$

Suppose we have an isolated conductor of radius $a$.

=1.0 true in

We can assign it a capacitance by assuming the other (outer) sphere is at infinity. So if we set $b = \infty$, then

$$\begin{eqnarray*} C = \frac{4\pi \epsilon _0}{1/a} = 4\pi\epsilon _0a \end{eqnarray*}$$

Numbers for Van de Graaf

$a \cong 10$ cm = 0.2 m
$\epsilon _0 = 8.85$ pF/m

$$\begin{eqnarray*} C &=& 4\pi\epsilon _0 a = 4\pi \left( 8.85\; \frac{\rm pF}{\rm... ...\ &\simeq & 10^{-6} C\qquad\qquad \mbox{small amount of charge} \end{eqnarray*}$$

Energy released

$$U = \frac{1}{2} C(\Delta V)^2 =\frac{1}{2} (11\times 10^{-12}F)(90,000 V)^2 = 4.5 \times 10^{-2}\;\;{\rm Joules}$$ (19)

If this is released in 1 second, power $= U/\Delta t = 0.045$ Watts.

Storing Energy in the $\vec{E}$ field

A capacitor stores .

We have seen that capacitors store charge. It turns out that charging capacitors is also a way to store energy.

=2.0 true in

To charge up a capacitor, you have to remove electrons from the positive plate and carry them to the negative plate. In doing so, you fight against the electric field, which is pulling them back toward the positive plate and repelling them from the negative plate. How much work does this take? If a voltage $\Delta V$ has already built up, $\Delta V = q/C$. The work done in transferring charge $dq$ (imagine $dq > 0$ being transferred from the negatively charged plate to the positively charged plate) is

$$\begin{eqnarray*} dW = \Delta V dq = \frac{q}{C} dq \end{eqnarray*}$$

The total work in going from $q = 0$ to $q = Q$ is

$$\begin{eqnarray*} W = \int dW = \int\limits^{Q}_{0} \frac{q}{C} dq = \frac{1}{2}\frac{Q^2}{C} \end{eqnarray*}$$

This work is stored as potential energy in the capacitor

Since $Q = C\Delta V, U = \frac{1}{2} C(\Delta V)^2$. So

The bigger the voltage or charge, the more the energy that is stored. An example of energy stored in a capacitor is a camera flash. Another example is the defibrillator that is used to restart the heart with electric shock. A capacitor stores the energy that is used to administer the electric shock.

is stored in an electric field.

Where is the energy residing? It is viewed as being stored in the electric field $\vec{E}$. It is customary to define an energy density $u$ as the potential energy per unit volume (of the space with $\vec{E}$). Consider a parallel plate capacitor with voltage difference $\Delta V$ and a uniform electric field $\vec{E} = \frac{\Delta V}{d} (-\hat{z})$. Using $C=\varepsilon_0 A/d$, we can write

$$\begin{eqnarray*} u &=& \frac{U}{\mbox{volume}} = \frac{U}{Ad} = \frac{1}{2} \fr... ...d}\quad\Longrightarrow\quad \mbox{\fbox{$u = \epsilon _0E^2/2$}} \end{eqnarray*}$$

Although we derived this result for the special case of a parallel plate capacitor, it holds in general. (Just imagine the field being uniform in a tiny element of space.) This formula is true even if there isn't a capacitor. If $E \neq 0$, $u = \epsilon _0E^2/2$. Note that superposition does not hold:

$$\begin{eqnarray*} \vec{E}= \vec{E}_1 + \vec{E}_2 \Longrightarrow \quad u &=& \fr... ...2)\\ &\neq &\frac{\epsilon }{2} \vec{E}^2_1 + \vec{E}^2_2 \end{eqnarray*}$$

So add fields and then square to get $u$.

Capacitor with Dielectric

A increases the capacitance.

It is common to find capacitors that are $1F$ but aren't 10 km on a side. How do we increase $C$ without increasing the dimensions of the capacitor?

Answer: We can place an insulator, such as plastic, glass, or oil, between the capacitor plates. This insulator is called a dielectric. It increases the capacitance by a numerical factor $\kappa$ called the dielectric constant. Thus, if we place a dielectric with dielectric constant $\kappa$ between the plates of a capacitor, the capacitance increases:

$$C = \kappa C_0$$ (20)

where $C_0$ is the capacitance without the dielectric. For a parallel place capacitor,

$$\begin{eqnarray*} C_0 = \epsilon _0 \frac{A}{d} \quad \Longrightarrow \quad C = \kappa C_0 = \kappa \epsilon _0\frac{A}{d} \end{eqnarray*}$$

$\kappa$ = 1 for vacuum. $\kappa \geq 1$ for all other materials. So $C \geq C_0$, i.e., the capacitance increases.

Why does this happen? Microscopically the molecules in the dielectric become polarized by the electric field between the plates of a charged capacitor. ``Polarized" means that the electric dipole moments of the molecules line up in the field. These dipole moments are either ``permanent" dipole moments (like H$_2$0) or ``induced" dipole moments (or both, i.e., permanent moments enhanced by induction). An induced dipole moment occurs when the external $\vec{E}$ field ``stretches" a molecule by separating the positive and negative charges a little. This creates a dipole moment.

=1.25 true in

Inside the dielectric there is no excess charge. On the surface near the positively charged plate, the dielectric has a build up of negative charge. Similarly, the negatively charged plate attracts a buildup of positive charge in the dielectric. The dielectric is neutral overall, i.e., no net charge, but it is polarized. The dielectric charges ``screen" the charges on the plate, making them less repulsive to each other and more willing to stay.

=2.0 true in

For example, the positive charge on the upper plate is attracted to the negative charge on the surface of the dielectric, so it is more willing to stay than before the dielectric was there. (This is like feeling more comfortable at a party if you know some people there.) Thus the dielectric enables us to put more charge on the capacitor plates, i.e., to increase the capacitance.

=2.0 true in

Notice that the induced field $\vec{E}_{ind}$ in the dielectric is opposite to $\vec{E}_{ext}$. As a result the total field $\vec{E}_{tot}$ between the plates is reduced.

$$\begin{eqnarray*} \vec{E}_{tot} = \vec{E}_{ext} + \vec{E}_{ind}, \qquad \vert\vec{E}_{tot}\vert < \vert\vec{E}_{ext}\vert \end{eqnarray*}$$

For a given amount of (free) charge $Q$ on the plates, $\Delta V$ is reduced when the dielectric is present. (``Free'' charge refers to the charge that is not induced.)

$$\Delta V = - \int \vec{E}_{tot} \cdot d\vec{s}$$ (21)

$$\begin{eqnarray*} && \frac{\mbox{empty}}{\Delta V_0=Q/C}\hspace*{2in} \frac{\mbo... ...\qquad\qquad\qquad\Longrightarrow \Delta V_{\kappa} < \Delta V_0 \end{eqnarray*}$$

where $Q$ is the free charge and $\kappa > 1$. To achieve a given voltage $\Delta V$ between the plates

$$\begin{eqnarray*} &&\quad Q_0 = C_0 \Delta V \hspace*{2in} Q_{\kappa} = \kappa C... ...V\\ && \qquad\qquad\qquad\qquad\Longrightarrow Q_{\kappa} > Q_0 \end{eqnarray*}$$

Therefore a capacitor can hold more free charge with the dielectric. Charging the capacitor to voltage $\Delta V$ stores energy $U$

$$\begin{eqnarray*} U_0=\frac{1}{2} \frac{Q^2_0}{C_0} = \frac{1}{2} C_0(\Delta V)^... ...Q^2_{\kappa}}{\kappa C_0} = \frac{1}{2} \kappa C_0 (\Delta V)^2 \end{eqnarray*}$$

More charge must be pumped onto the dielectric capacitor to achieve a given voltage $\Delta V$. This takes more work. So more energy $U_{\kappa}$ is stored.

Putting free charge $Q$ on the capacitor stores energy $U$

$$\begin{eqnarray*} U_0 = \frac{1}{2} C_0 \Delta V_0^2 = \frac{1}{2} \frac{Q^2}{C_... ... C_0 (\Delta V)^2_{\kappa} = \frac{1}{2} \frac{Q^2} {\kappa C_0} \end{eqnarray*}$$

It takes less work to put $Q$ on the dielectric capacitor because the charge is screened.

Gauss' law when a dielectric is present:

$$\begin{eqnarray*} \epsilon _0 \oint \kappa \vec{E}\cdot d\vec{a}= q_{\rm free} \end{eqnarray*}$$

Capacitors in Circuits

Capacitors are important circuit elements. One way to charge a capacitor is to attach it to a battery. You can think of a battery as a pump which takes plus charge from the negatively charged plate and adds it to the positively charged plate.

=2.0 true in

The battery keeps doing this until the voltage across the terminals of the battery equals the voltage across the capacitor plates. Let's draw a circuit diagram to show the setup for doing this. An electric circuit is the path through which current flows.

=3.0 true in

Current starts to flow and the capacitor starts charging once the switch $S$ is closed. Once $C$ is charged, it will stay charged even if $S$ is opened, i.e., $+q$ and $-q$ stay on the plates.

Sometimes we have more than one capacitor in a circuit. It is convenient to replace combinations of capacitors with an equivalent capacitor $C_{eq}$. This simplifies the circuit. There are two basic combinations.

Capacitors in Parallel

Add capacitances to find the equivalent capacitance $C_{eq}$ of capacitors in .

=2.5 true in

Capacitors are connected in parallel when a potential difference applied across their combination results in that potential difference being applied across each capacitor. The equivalent capacitor has the same amount of charge as all the parallel capacitors combined and the same potential drop as all capacitors combined. In the case shown

$$\begin{eqnarray*} q_1 &=& C_1\Delta V\qquad\quad q_2 = C_2\Delta V\qquad\quad q_... ...\\ &=& C_{eq}\Delta V\quad \mbox{where}\quad C_{eq}=C_1+C_2+C_3 \end{eqnarray*}$$

$C_{eq}$ is the equivalent capacitance of the single capacitor.

=2.0 true in

In general,

$$\begin{eqnarray*} C_{eq} = \sum^{n}_{i=1}C_i\qquad \mbox{for capacitance in parallel} \end{eqnarray*}$$

Add the capacitances for capacitors in parallel.

Capacitors in Series

Add capacitances to find the equivalent inverse capacitance $1/C_{eq}$ of capacitors in .

=2.0 true in

Capacitors are connected in series when the potential difference applied across the combination is the sum of the potential differences across each capacitor. $C_{eq}$ has the same $q$ and the same $\Delta V$ as the whole combination.

=2.0 true in

Notice that each capacitor in the series has the same amount of charge on it. To see this, note that the boxed conductor is electrically isolated and therefore has no net charge. The charges are merely separated into $+q$ and $-q$. No charge can be transferred to the isolated element.

$$\begin{eqnarray*} q &=& C_1\Delta V_1\qquad\quad q = C_2\Delta V_2 \qquad\quad q... ...elta V_2 = \frac{q}{C_2} \qquad\quad \Delta V_3 = \frac{q}{C_3} \end{eqnarray*}$$

By the definition of being in series,

$$\begin{eqnarray*} \Delta V &=& \Delta V_1 + \Delta V_2 + \Delta V_3 = \frac{q}{C... ...rac{1}{C_{eq}} &=& \frac{1}{C_1} + \frac{1}{C_2} + \frac{1}{C_3} \end{eqnarray*}$$

$$C_{eq} = \frac{1}{\frac{1}{C_1}+\frac{1}{C_2}+\frac{1}{C_3}}$$ (22)

=2.0 true in

In general, for $n$ capacitors in series

$$\frac{1}{C_{eq}} = \sum^{n}_{i=1}\frac{1}{C_{i}}$$ (23)
